GENERAL FEATURES
Digital colour entrance panel 322010 Embedded 325 x 125 x 60,5 30 V / 110 mA 30 V / 290 mA
Entrance panel with call address list 322011 Embedded 325 x 125 x 44,5 30 V / 25 mA 30 V / 245 mA
Small entry panel color 322020 Wall mount 141 x 108 x 31 0 Vdc/ 0 mA 12 V / 250 mA
Floor call entry panel 322021 Wall mount 125 x 104 x 25 0 Vdc/ 0 mA
10 Call pushbuttons entrance panel 322030 Embedded 325 x 125 x 63 30 V / 14 mA 30 V/ 230 mA
20 Call pushbuttons entrance panel 322031 Embedded 325 x 125 x 63 30 V / 14 mA 30 V / 230 mA
3.5" Handsfree internal unit 321011 Wall mount 139,5 x 193,5 x 29 30 V / 20 mA 30 V / 85 mA
3.5" Handsfree internal unit 321060 Wall mount 158 x 165 x 29 30 V / 15 mA 30 V / 85 mA
4,3" Handsfree internal unit 321061 Wall mount 120x179x22.5 30 V / 13 mA 30 V / 90 mA
7" Touch screen internal unit 321070 Wall mount 157 x 198 x 17 30 V / 100 mA 30 V / 200 mA
10" Touch screen internal unit 321071 Wall mount 198 x 255 x 27 30 V / 100 mA 30 V / 200 mA
Audio Internal white 322040 Wall mount 141 x 91 x 34 30 V / 30 mA 30 V / 70 mA
Colour hands free 7" alarm 322050 Wall mount 175 x 260 x 23 30 V / 20 mA 30 V / 145 mA
Colour hands free 7" 322052 Wall mount 155 x 225 x 29 30 Vdc
Porter switchboard 323001 Table 290 x 170 x 165 30 Vdc 30 V / 280 mA
Surface-mounting boxes 1 module 322001
Surface-mounting boxes 2 module 322002
Targa module 322012 Embedded 325 x 125 x 44,5 30 V / 5 mA 30 V / 25 mA
16 Additional pushbuttons panel 322032 Embedded 325 x 125 x 44,5 30 V / 5 mA 30 V / 28 mA
32 Additional pushbuttons panel 322033 Embedded 325 x 125 x 44,5 30 V / 5 mA 30 V / 28 mA
Floor shunt 323002 DIN Rail 72 x 105 x 33 30 V / 25 mA 30 V / 130 mA
Riser shunt 323003 DIN Rail 106 x 105 x 33 30 V / 60 mA 30 V / 110 mA
Entrance panel video mixer 323004 DIN Rail 72 x 105 x 33 30 V / 20 mA 30 V / 60 mA
Power supply 323005 Wall mount 167,5 x 161 x 85 220 V 30 V / 2 A
2 Branches video splitter 323007 DIN Rail 72 x 105 x 33 30 V / 25 mA 30 V / 70 mA
Basic apartment interface 323008 DIN Rail 72 x 105 x 33 30 V / 40 mA 30 V / 140 mA
Apartment interface 323009 DIN Rail 141 x 105 x 33 30 V / 40 mA 30 V / 140 mA
Auxiliary power supply 323010 Wall mount 167,5 x 161 x 85 AC input 220 V DC output 30 V / 2 A
D45/IP interface 323011 DIN Rail 90 x 175 x 60 30 V / 130 mA 30 V / 230 mA
SF4 Switchboard software 323012 Laptop Windows
quipped
Distric generator 323013 DIN Rail 175 x 105 x 66 30 V / 100 mA 30 V / 300 mA
Door lock accessory 323015 DIN Rail 72 x 105 x 33 30 V / 30 mA 30 V /30 mA
Villa shunt 323016 DIN Rail 72 x 105 x 33 30 V / 20 mA 30 V / 160 mA
Lift control interface module 323017 DIN Rail 141 x 105 x 33 30 V / 15 mA 30 V / 30 mA
EP/Switchboard shunt 323018 DIN Rail 72 x 105 x 33 30 V / 70 mA 30 V / 70 mA
System expansion interface 323019 DIN Rail 106 x 105 x 33 30 V / 50 mA 30 V / 80 mA
Conguration tool kit 323020 48 x 48
Accessory for additional camera 323021 DIN Rail
Floor shunt with one output module 323022 44 x 30 x 20 30 V / 10 mA 30 V / 80 mA
SEP video mixer 323023 DIN Rail 141 x 105 x 33 30 V / 15 mA 30 V / 1 A
D45/2-wire interface 346858 DIN Rail 72 x 105 x 33 30 V / 1 mA 30 V / 20 mA
TYPE MODEL NAME CODE NUMbER FIXINg WAY DIMENSIONS (MM) CURRENT STANDbY AbSORPTION WORK
ENTRANCE
PANNELS
HANDSETS
ACCESSORIES
Products list and main features
12
