LELY ASTRONAUT A4 User Manual

5.1004.8641.0 B
Diagrams 6-1
6 Diagrams
6.1 Gate Guard Set
6.1.1 Gate Guard Set Examples
The stand poles and additional tubing for the gate guard set are not provided in the set
and must be bought externally. The diameter of the stand poles must be 76 mm (2.5 in).
To avoid cows are harmed, avoid protruding parts. Make sure the height (E, F) of the
stand poles (4) does not extend the t-clamps (5) (see figure 41 on page 6-3).
Make sure the stand poles are not installed to the robot unit.
Always install the guard set in line with the side fence of the milking robot.
