LELY ASTRONAUT A4 User Manual

5.1004.8641.0 B
Diagrams 6-3
6.1.2 Gate Guard Set Dimensions
A
B
E
4
F
44
555
C
=
=
D
D
D
1
B
C
D
D
D
3
=
=
2
B
Figure 41. Gate guard set with self-made additional tubing
KEY: 1. B = <235 mm (9.3 in) or >300 mm (11.8 in) - 2. B = >235 mm (9.3 in) and <300 mm (11.8 in) - 3. Extra additional tubing - 4. T-
clamp - 5. Stand pole (3x)
For dimensions see (see table 2 on page 6-4).
