Accessories (overview)
EMC accessories
Shield mounting
11
l
156
EDS700ACBA EN 5.1
11.9 EMC accessories
11.9.1 Shield mounting
EZAMBHX
[mm]
EZAMBHXM006
(<− E94AZJS003)
2 18 20 4 ... 15
EZAMBHXM003
(<− E94AZJS007)
3 19 30 10 ... 20
EZAMBHXM004
(<− E94AZJS024)
4 27 30 15 ... 28
EZAMBHXM005 5 37 35 20 ... 37
EZAMB_010
EZAMBHXM007 20 mm 4 ... 10 mm
