Lenze E70ACPSE Series User Manual

Mechanical installation
Dimensions
Devices with "cold plate" design
5
l
70
EDS700ACBA EN 5.1
5.3.3 Devices with "cold plate" design
i700P011 b
h b t h1 h2 h3 h4 t1 t2
[A] [mm] [kg]
E70ACPSC0304x 30 350 50 221
410 20 40 452 235 −
2.1
E70ACPSC0604x 60 350 100 221 5.4
E70ACMxC0054xx1xxx 5
350 50 221
410 20 40 452 235 −
2.3
E70ACMxC0104xx1xxx 10 2.3
E70ACMxC0204xx1xxx 20 2.3
E70ACMxC0054xx2xxx 2 * 5 2.5
E70ACMxC0104xx2xxx 2 * 10 2.5
E70ACMxC0324xx1xxx 32
350 100 221
5.3
E70ACMxC0484xx1xxx 48 5.3
E70ACMxC0644xx1xxx 64 5.3
E70ACMxC0204xx2xxx 2 * 20 5.3
E70ACMxC0324xx2xxx 2 * 32 5.3
