Lenze E70ACPSE Series User Manual

Mechanical installation
Drilling the holes into the mounting plate
5
l
67
EDS700ACBA EN 5.1
5.2 Drilling the holes into the mounting plate
Mounting grid
We recommend to provide the mounting plate with a grid pattern of M5 threaded holes
for attaching the devices. This preparation enables easy attachment of the devices and the
device sizes 1 (b = 50 mm) and 2 (b = 100 mm) can thus be mounted directly adjacent to
each other.
) Note!
ƒ M5 screw and washer assemblies or hexagon socket screws with washers
are permitted.
ƒ Tightening torque: 3.4 Nm / 30 lb−in.
