3.4 Product key
1 ... 4 5 6 7 8 9 ... 11 12 13 14 15 16, 17 18
Power supply E70A C P S x xxx 4 x
Servo inverter E70A C M x x xxx 4 x x x xx x
Product series
Servo inverter i700
Mounting type
C = control cabinet
Version
M = axis module (servo inverter)
P = power supply module
Version
D = < 599 Hz
S = > 599 Hz or standard
Mounting type
E = built−in technique
D = push−through technique
C = cold plate technique
Output current e.g.
005 = 5 A
060 = 60 A
Voltage class
4 = 400/480 V, 3/PE AC
Ambient conditions
S = standard industrial environment IE33 according to IEC 60721−3−3
V = rough environment (coated printed circuit boards)
Safety system
A = with integrated safety engineering "Basic Safety − STO"
B = with integrated safety engineering "Extended Safety"
Number of axes
1 = single axis module (single inverter)
2 = double axis module (double inverter)
Communication
ET = EtherCAT®
Type of encoder
R = resolver
E = SinCos encoder
The nameplate serves to identify delivered products by nameplate data. The product catalogue provides information
on the possible configuration to order the products.
