Mechanical installation
Important notes
5
l
66
EDS700ACBA EN 5.1
5 Mechanical installation
5.1 Important notes
{ Danger!
Sticker with warning note must be displayed prominently and close to the
device!
) Note!
The devices must be installed in housings (e.g. control cabinets) to meet
applicable regulations.
Summary of important notes on mechanical installation
ƒ Mount the devices vertically (¶ 30)
– DC−bus voltage connections (X101/102): at the top
– Fan unit: at the bottom
ƒ Observe mounting clearances (¶ 30):
– If unimpeded ventilation of the modules is ensured, the connecting cables can be
installed in the mounting clearances
– The modules can be mounted side−by−side without any clearance
ƒ Requirements for the mounting and supporting surface to ensure an EMC−compliant
installation without the need for additional measures:
– Electrically conductive
– Free of lacquer and protected against corrosion or made of rust−proof metal
– Completely flat and smooth surface
ƒ In case of push−through installation (thermal separation), the heatsink protrudes
through the mounting cutout of the mounting wall.
– The design of the mounting wall must ensure the tightness towards the device
surface.
– Prevent the mounting wall from being bent or twisted.
ƒ In order to comply with the permissible pollution degree of the ambient air, (¶ 29)
provide additional measures:
– Separate or filtered air flow against dust, fluff, grease, aggressive gas
– Ensure regular cleaning
ƒ Observe permissible ambient temperatures − also in the control cabinet (¶ 29).
