Technical data
Overcurrent operation
Supply modules
4
l
44
EDS700ACBA EN 5.1
4.3.1 Supply modules
Power supply
modules
Short−time currents [A] acc. to cycle times
3 / 12 s 60 / 120 s
I
rdc
200%
I
max_3
75%
I
red_12
150%
I
max_60
75%
I
red_120
E70ACPSx0304x 30.0 60.0 19.8 45.0 22.5
E70ACPSx0604x 60.0 120 39.6 90.0 45.0
4.3.2 Axis modules
Axis modules
Short−time currents [A] at switching frequency of 4 kHz acc. to cycle times
3 / 12 s 60 / 120 s
I
r4
200%
I
max4_3
75%
I
red4_12
150%
I
max4_60
75%
I
red4_120
E70ACMxx0054xx1xxx 2.5 5.0 1.9 3.8 1.9
E70ACMxx0104xx1xxx 5.0 10.0 3.8 7.5 3.8
E70ACMxx0204xx1xxx 10.0 20.0 7.5 15.0 7.5
E70ACMxx0324xx1xxx 16.0 32.0 12.0 24.0 12.0
E70ACMxx0484xx1xxx 24.0 48.0 18.0 36.0 18.0
E70ACMxx0644xx1xxx 32.0 64.0 24.0 48.0 24.0
E70ACMxx0054xx2xxx 2 * 2.5 2 * 5.0 2 * 1.9 2 * 3.8 2 * 1.9
E70ACMxx0104xx2xxx 2 * 5.0 2 * 10.0 2 * 3.8 2 * 7.5 2 * 3.8
E70ACMxx0204xx2xxx 2 * 10.0 2 * 20.0 2 * 7.5 2 * 15.0 2 * 7.5
E70ACMxx0324xx2xxx 2 * 16.0 2 * 32.0 2 * 12.0 2 * 24.0 2 * 12.0
