Configuration
Basic configurations
2−4
l
EDSVS9332P−EXT DE 2.0
2.2 Basic configurations
( Stop!
It is possible to load predefined basic configurations via code C0005. If you load a
configuration via C0005, the assignment of all inputs and outputs will be overwritten
with the corresponding basic configuration.
Adapt the function assignment to the wiring.
The internal signal processing is adapted to the drive task by selection of a predefined basic
configuration in C0005. Lenze setting: C0005 = 20000 (standard absolute positioning).
l Application examples of basic configurations can be found in the chapter "Application
examples".
l Before you can load a basic configuration via C0005, the controller must be inhibited.
The selection numbers in C0005 have the following meaning:
C0005 = 1 0 0 0 = Speed control
C0005 = 2 X X X X
Device control
0 = Control via control terminals
1 − Control via LECOM A/B/LI
3 − Control via AIF (INTERBUS,PROFIBUS)
5 − Control via system bus (CAN)
Voltage source for the control terminals
0 = External supply voltage
1 = Internal supply voltage
0 = Absolute positioning
2 = Relative positioning
0 = Positioning via home position
2 = Positioning via position switch points and with teach function
6 = External path control
2 = Positioning control
