Function library
Function blocks
3.5.38 Free digital outputs (FDO)
3−194
l
EDSVS9332P−EXT DE 2.0
Signal Source Note
Name Type DIS DIS format CFG List Lenze
FDO−0 d C0151 hex C0116/1 2 1000
FDO−1 d C0151 hex C0116/2 2 1000
FDO−2 d C0151 hex C0116/3 2 1000
FDO−3 d C0151 hex C0116/4 2 1000
FDO−4 d C0151 hex C0116/5 2 1000
FDO−5 d C0151 hex C0116/6 2 1000
FDO−6 d C0151 hex C0116/7 2 1000
FDO−7 d C0151 hex C0116/8 2 1000
FDO−8 d C0151 hex C0116/9 2 1000
FDO−9 d C0151 hex C0116/10 2 1000
FDO−10 d C0151 hex C0116/11 2 1000
FDO−11 d C0151 hex C0116/12 2 1000
FDO−12 d C0151 hex C0116/13 2 1000
FDO−13 d C0151 hex C0116/14 2 1000
FDO−14 d C0151 hex C0116/15 2 1000
FDO−15 d C0151 hex C0116/16 2 1000
FDO−16 d C0151 hex C0116/17 2 1000
FDO−17 d C0151 hex C0116/18 2 1000
FDO−18 d C0151 hex C0116/19 2 1000
FDO−19 d C0151 hex C0116/20 2 1000
FDO−20 d C0151 hex C0116/21 2 1000
FDO−21 d C0151 hex C0116/22 2 1000
FDO−22 d C0151 hex C0116/23 2 1000
FDO−23 d C0151 hex C0116/24 2 1000
FDO−24 d C0151 hex C0116/25 2 1000
FDO−25 d C0151 hex C0116/26 2 1000
FDO−26 d C0151 hex C0116/27 2 1000
FDO−27 d C0151 hex C0116/28 2 1000
FDO−28 d C0151 hex C0116/29 2 1000
FDO−29 d C0151 hex C0116/30 2 1000
FDO−30 d C0151 hex C0116/31 2 1000
FDO−31 d C0151 hex C0116/32 2 1000
Function
You can freely select a digital signal source for every signal input.
l The corresponding bit in the data word (DWORD) is marked with FDO−x (e.g. FDO−0 for the
LSB and FDO−31 for the MSB).
l The DWORD is transferred to code C0151 and to the function blocks AIF−OUT, CAN−OUT1,
CAN−OUT2, and CAN−OUT3.
