Configuration
Change of the terminal assignment
2.4.1 Freely assignable digital inputs
2−12
l
EDSVS9332P−EXT DE 2.0
2.4 Change of the terminal assignment
(see also chapter 3.1 "Working with function blocks")
If the configuration is changed via C0005, the assignment of all inputs and outputs is overwritten with
the corresponding basic assignment. If necessary, the function assignment must be adapted to the
wiring.
Tip!
Use the menu "Terminal I/O" for the keypad 9371BB or the menu "Terminal I/O" for Global Drive
Control or LEMOC2.
Stop!
If you reassign an input, the signal source that has been assigned up to know will not be overwritten!
Those active connections that are not required must be removed (see chapter 3.1.3).
2.4.1 Freely assignable digital inputs
Five freely assignable digital inputs are available (X5/E1 … X5/E5). You can define a polarity for each
input which serves to determine the input to be HIGH active or LOW active.
Change assignment:
Tip!
Use the submenu "DIGIN" for the keypad 9371BB or the submenu "Digital inputs" for Global Drive
Control or LEMOC2.
