3.5.45 Monitor outputs of monitoring system (MONIT)
3−219
l
EDSVS9332P−EXT DE 2.0
MONIT outputs
MONIT output Description
CE0 Communication error − automation interface (AIF)
CE1 Communication error − process data input object CAN1_IN
CE2 Communication error − process data input object CAN2_IN
CE3 Communication error − process data input object CAN3_IN
CE4 BUS−OFF state of system bus (CAN)
EEr External monitoring, triggered via DCTRL
H05 Internal fault (memory)
H07 Internal fault (power section)
H10 Thermal sensor error − heatsink
H11 Thermal sensor error − inside the device
LP1 Motor phase failure
LU Undervoltage in the DC bus
nErr Speed control error
NMAX Maximum speed (C0596) exceeded
OC2 Earth fault − motor cable
OC5 I x t overload
OC6 I
2
x t overload
OC8 I
2
x t overload advance warning
OH Heatsink temperature > +90 °C
OH3 Motor temperature > +150 °C threshold
(temperature detected via resolver or incremental value encoder)
OH4 Heatsink temperature > C0122
OH7 Motor temperature > C0121
(temperature detected via resolver or incremental value encoder)
OH8 Motor temperature measured via inputs T1 and T2 too high
OU DC−bus overvoltage
P03 Following error
P16 Faulty transmission of sync telegram on system bus (CAN)
P19 Limitation of input values at X9
PL Error during rotor position adjustment
Sd2 Resolver error at X7
Sd3 Encoder error at X9
Sd5 Encoder error at X6 pins 1 and 2
Sd6 Thermal sensor error − motor (X7 or X8)
Sd7 Absolute value encoder at X8
Initialisation error or communication error during rotor position adjustment
Sd8 Sin/cos encoder at X8 transmits no or inconsistent data
