Lenze EVS9322EP User Manual

Function library
Function blocks
3.5.69 Variable table − speed (VTVEL)
3−282
l
EDSVS9332P−EXT DE 2.0
Function
A total of 34 table positions is available.
l Enter fixed setpoints under C1302.
– 30 table positions (VTVEL−No1 ... VTVEL−No30) are available.
– Subcodes (C1302/1 ... C1302/30) define the table position number.
l Enter variable setpoints under VTVEL−INx.
– Four table positions (VTVEL−No31 ... VTVEL−No34) are available.
– Signal input via function blocks.
– The setpoints must be transmitted to the table positions before the program set starts and
has access to it.
l C1382 indicates the setpoints (in % of vmax) on the table positions.
– Select table position (C1382/1 ... C1382/34) with subcode.
l C1383 displays the setpoints (in inc) on the table positions.
– Select table position (C1383/1 ... C1383/34) with subcode.
l The conversion from v [units/s] to v [inc] is performed according to the formula:
v[inc] + v[unitsńs] @
65536[incńr] @ gearnominator @ 16384
Feedconst.[unitsńr] @ geardenominator @ 1000[1ńs]
Tip!
Entries into the processing table are only required if FB inputs and outputs are used.
