Designs “Feedback systems"
Design i750 "Hiperf
ace DSL® (OCT)/PTC"
Funcon can be selected via parameters
One Cable Technology (OCT) via Hiperface DSL®
•
Encoder connecon on X109
•
Digital temperature evaluaon via encoder cable
•
Usable Lenze motors with Hiperface DSL® encoder:
-
Servo motors m850, MCS
PTC
•
PTC connecon on X109
•
Motor encoder evaluaon is not possible
•
Usable Lenze motors with PTC/TKO:
-
Three-phase AC motors m550, m540, MF
Design i750 "Resolver"
•
Enc
oder connecon on 9-pin Sub-D
•
X109 without funcon
•
Temperature evaluaon via encoder cable
•
Usable Lenze motors with resolver:
-
Servo motors m850, MCS, MCA, MQA
-
Three-phase AC motors m550, m540, MF
Design i750 "Mul-Encoder"
•
Encoder connecon on 15-pin Sub-D
•
X109 without funcon
•
Temperature evaluaon via encoder cable
•
Supported incremental encoders: SinCos, TTL
•
Supported absolute value encoders: HIPERFACE®, SSI, SinCos+SSI
•
Usable Lenze motors with encoder:
-
Servo motors m850, MCS, MCA, MQA
-
Three-phase AC motors m550, m540, MF
Example: Single axes and double axes 1.1 kW ... 4 kW
Design i750 "Hiperface DSL® (OCT)/PTC" Design i750 "Resolver" Design i750 "Mul-Enc
oder"
Product in
formaon
Product descripon
Product variants
16
