Lenze i950 Series User Manual

Fusing data
A residual current device (RCD) is oponal.
Inverters Fuse Circuit breaker RCD
Characterisc
Max. rated
curr
ent
Characterisc
Max. rated
current
Type
A A mA
I95AE155F gG/gL, gRL 10 B 10 ≥30 Typ B
I95AE175F gG/gL, gRL 10 B 10 ≥30 Typ B
I95AE222F gG/gL, gRL 16 B 16 ≥30 Typ B
I95AE240F gG/gL, gRL 16 B 16 ≥30 Typ B
I95AE275F gG/gL, gRL 50 B 50 ≥30 Typ B
I95AE311F gG/gL, gRL 50 B 50 ≥30 Typ B
I95AE315F gG/gL, gRL 50 B 50 ≥30 Typ B
I95AE322F gG/gL, gRL 63 B 63 ≥300 Typ B
I95AE330F gG/gL, gRL 80 B 125 ≥300 Typ B
I95AE345F gG/gL, gRL 125 B 125 ≥300 Typ B
I95AE355F gR 160 B 160 ≥300 Typ B
I95AE375F gR 160 B 160 ≥300 Typ B
I95AE390F gR 300 B 300 ≥300 Typ B
I95AE411F gR 300 B 300 ≥300 Typ B
Electrical ins
tallaon
Mains connecon
3-phase mains connecon 480 V
147

Lenze i950 Series Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Altitude	Up to 1000 m without derating
Control Modes	V/f control, vector control, servo control
Communication Interfaces	EtherCAT, PROFINET, CANopen, Modbus TCP
Ambient Temperature	-10°C to 40°C
Safety	STO (Safe Torque Off), SS1 (Safe Stop 1), SLS (Safely Limited Speed)
Cooling Method	Air cooling
Frequency Range	0 to 599 Hz
Relative Humidity	5% to 95% (non-condensing)
Input Voltage	200 V to 480 V
Output Voltage	0 V to 480 V
Storage Temperature	-25 to +70 °C (-13 to 158 °F)
