24 V supply for motor holding brake
Terminal X107: supply voltage brake + / -
24B, GB
DC supply of X106
External power supply unit
specicaon
SELV/PELV
Rated input voltage V +24 ± 20 %
Max. Input current 0.37 ... 15 kW A 2.5 Typical: according to the load at X106
22 ... 110 kW A 5.0
Polarity reversal protecon Yes
Suppressor circuit Yes Suppressor diode 30 V, bidireconal
Connecon descripon Motor brake 24 V supply for motor brake
Connecon X106 X107
Connecon type Pluggable Pluggable
Max. cable cr
oss-secon mm² 1.5 2.5
Max. cable cr
oss-secon AWG 16 12
Stripping length mm 9 10
Stripping length in 0.35 0.39
Required tool 0.4 x 2.5 0.6 x 3.5
Electrical ins
tallaon
Motor holding brake connecon
154
