Removing the optional finisher

To remove the optional finisher, its bins, and its stand, complete the following sections.

Preparing for disassembly

1 Turn the power off.

2 Remove all print media from the bins.

Removing the bins

1 Grasp the top bin (bin 1) and tilt it up.

2 Pull the bin straight out
