5. Piping Diagrams
Piping diagrams
Heat Exchanger
C
.
F.
F.
lndoor unit
EEV
:Heating
:Cooling
Filter
Filter
:
Ther
mistor
Heat Exchanger
Sirocco F
an
lndoor unit
EEV
:Heating
:Cooling
Filter
Filter
:
Ther
mistor
Refrigerant pipe connection port diameter
MODEL
GAS
LIQUID
ARNU09GVEA1
ARNU12GVEA1
Ø12.7(1/2)
Ø6.35(1/4)
ARNU18GVJA1
ARNU24GVJA1
Ø15.88(5/8)
Ø9.52(3/8)
[unit: mm(inch)]
VE
VJ
149
151
