- 52 -
Copyright ©2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. Specification
Specification
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
Heating • Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
• Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. EEV : Electronic Expansion Valve
5. To be added for more available Models
Type
Model Unit
W
Cooling Capacity kcal/h
Btu/h
W
Heating Capacity kcal/h
Btu/h
Dimensions (W*D*H)
Body
mm
inch
Coil
Rows x Columns x FPI
Face Area m
2
Type
Motor Output x Number
W
Running Current A
Fan Air Flow Rate(H/M/L) cmm
cfm
Drive
Motor type
Temperature Control
Sound Absorbing Thermal Insulation Material
Air Filter
Safety Device
Liquid Side mm(inch)
Pipe Connections
Gas Side mm(inch)
Drain Pipe(Internal Dia.)
mm
Net Weight kg(lbs)
Noise Level
(Sound Press, 1m, H/M/L)
dBA±3
Power Supply Ø / V / Hz
Refrigerant Control
Power cable mm
2
Transmission cable mm
2
Front Panel('*' Position)
ARTCOOL
ARNU07GSP*1 ARNU09GSP*1 ARNU12GSP*1
2,200 2,800 3,600
1,900 2,400 3,100
7,500 9,600 12,300
2,500 3,200 4,000
2,200 2,800 3,400
8,500 10,900 13,600
570x137x568 570x137x568 570x137x568
22.4x5.4x22.3 22.4x5.4x22.3 22.4x5.4x22.3
2x20x20 2x20x20 2x20x20
0.16 0.16 0.16
Turbo Fan Turbo Fan Turbo Fan
30 30 30
0.14 0.14 0.14
6/5.5/5 7/ 6.5 /6 8.7/ 8.1 /7.5
212/194/177 247/230/212 307/286/265
Direct Direct Direct
BLDC BLDC BLDC
Microprocessor, Thermostat for cooling and heating Microprocessor, Thermostat for cooling and heating Microprocessor, Thermostat for cooling and heating
Foamed polystrene Foamed polystrene Foamed polystrene
Net(Washable) Net(Washable) Net(Washable)
Fuse Fuse Fuse
Ø6.35(1/4) Ø6.35(1/4) Ø6.35(1/4)
Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2)
12.2 12.2 12.2
12(26.5) 12(26.5) 12(26.5)
38/34/32 40/36/33 42/38/36
1, 220 ~ 240, 50 1, 220 ~ 240, 50 1, 220 ~ 240, 50
1, 220, 60 1, 220, 60 1, 220, 60
EEV EEV EEV
CV2.0 X 3C CV2.0 X 3C CV2.0 X 3C
CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C
M:Metal, D:Wood, B:Blue, W:White
