D9U001PPB-0101 31/106
7.2 Technical parameters
Total length of the lying area
(including the foot section)
2 122 mm (83.54 inch)
Minimum length in the default setting
(without the foot section)
1 570 mm (61.81inch)
Full width with the side rails in active position 980 mm (38.58 inch)
Full width with the side rails in parked position 960 mm (37.79 inch)
Maximum height of the seat section
(Trendelenburg 40°)
1143 mm (45 inch)
Upholstery width (maximum) 890 mm (35.04 inch)
Upholstery length (maximum) 2 050 mm (80.71 inch)
Castor size 150 mm (5.91 inch)
Height of the supporting area including upholstery
(seat section):
Minimum 600 mm + 20 mm (23.62 inch + 0.78 inch)
Maximum 1 050 mm + 20 mm (41.34 inch + 0.78 inch)
Vertical lift 450 mm (17.72 inch)
Vertical speed up (with max patient load) 11.25 mm/s (0.44 inch/s)
Vertical speed down (with max patient load) 20.45 mm/s (0.81 inch/s)
Upholstery thickness:
Foot section 65 mm (2.56 inch)
Back section 100/130 mm (3.93/5.11 inch)
Seat section 100/130 mm (3.93/5.11 inch)
Adjustment angles:
Back section positioning angle -10°/+70°
Seat section positioning angle 0°/+18.5°
Trendelenburg position -10°
Leg rests vertical adjustment angle 0°/+143°
Leg rests horizontal adjustment angle +60°
Foot section adjustment angle 0°- 22°
Stickers, labels material polymeric PVC foil
Maximum patient load 240 kg (529 lb)
Safe working load 255 kg (562 lb)
Overall product weight without accessories 245 kg (540 lb)
Overall weight of the upper part of the birthing bed
including accessories
140 kg (308 lb)
Overall weight of the lower part of the birthing bed
including accessories
96 kg (211 lb)
