D9U001PPB-0101 43/106
9.1.1 Description of the control panel for the woman in childbirth
Lowering / lifting
of back section
Height
adjustmentí
9.1.2 Adjustment of the handle in inactive position
► To initiate lowering, push the trigger in the marked direction with one hand, then lower the rail
to the lowest position possible. The parking position is suitable for birth mother to get easily
on the bed, eventually for better access to the patient during birth
9.1.3 Adjustment of the handle in active position
► In the active position, you only need to pull the handle to the highest position. The rail locks in
the active position automatically
