D9U001PPB-010148/106
9.5.1 Folding/unfolding
WARNING!
Before folding, always make sure the foot section is in the lowest position and
back section is not in Trendelenburg position
WARNING!
In case of putting aside the upholstery of the foot section from the bed, it must
be placed on its wide laying surface on flat surface such as ground or bed. In
case of lying the foot section on the edge side, the upholstery may be damaged
due to heavy weight of the part.
WARNING!
When unfolding the foot section, other person(s) must not interfere
In lowered position, the foot section can be folded and locked in two positions:
► FOLDED
(the part is hidden under the seat section)
► UNFOLDED
► Adjustment to any of these positions can
be done by pressing the controller in the
direction of the marked arrow and turning
the foot section towards/outwards the
operator.
► Once reached, the foot section will
automatically lock in both positions.
