D9U001PPB-0101 47/106
9.5 Setting of the foot section
WARNING!
The load capacity of foot section is 150 kg maximum (330 lb)
WARNING!
The load capacity of foot section and leg rests together is 170 kg maximum
(374 lb)
WARNING!
Do not overload the footrest due to the unsecured position. It is necessary to
always secure the part in the end positions (parking, active)!
WARNING!
Foot section positioning (sliding in/out, lifting/lowering, inclination) always
without load.
Folding/unfolding
Tilting up/down
Lifting/lowering
