D9U001PPB-010144/106
9.2 Side control panel
WARNING!
Side control panel is located on both sides of AVE2 birthing bed. The panel can
be operated by trained personnel only
Nurse Call
Holding the button initiates
setting the bed to anti-shock
position
Stopping bed movement
Under carriage light on/off
(optional)
Locking of the bed control. You activate
the control lock with pressing the button
(when the diode beams, it is activated).
For deactivation hold the button for at
least 3 seconds (it is deactivated when
the diode does not beam)
Lowering / lifting of
the seat section
Indication of
mains connection
Lowering /
lifting of the
back section
Bed height
adjustment
CPR leverBattery status
indicator
