4 -36
(9) Recommended Maximum Specification of Implements
No. Implements Specification MT230E/-HE MT235E/-HE MT240E/-HE
1 Trailer Total weight See chapter 4-5-(3) in this manual.
2 Mid mower Max cutting width
1676 mm
(66 in.)
3
Rear mounted
mower
Max cutting width
1676 mm
(66 in.)
4 Flail Mower Max cutting width
1524 mm
(60 in.)
5 Sickle Bar Max cutting width
1676 mm
(66 in.)
6
Rear mounted
Sprayer
Total weight
(Sprayer+Liquid)
250 kg
(551 lb)
7 Pull type Sprayer Total weight See chapter 4-5-(3) in this manual.
8 Rotary Tiller Max tilling width
1520 mm
(59.0 in.)
1520 mm
(59.0 in.)
1600 mm
(63 in.)
9 Furrow Plow Max tilling width
1520 mm
(59.0 in.)
1520 mm
(59.0 in.)
1600 mm
(63 in.)
10 Bottom Plow Maximum size
1250 mm
(49 in.)
11
Disk harrow
(pull type)
Max harrowing width -
12 Chisel Plow Maximum width
1500 mm
(59 in.)
13 Front grader Max working width
1660 mm
(65 in.)
14 Rear blade Max working width
1524 mm
(60 in.)
15 Front loader
Max lift capacity
(Bucket pivot point)
990 kg
(2182 lb)
16 Landscape Rake Max working width
1829 mm
(72 in.)
17 Box blade Max working width
1520 mm
(59.0 in.)
1520 mm
(59.0 in.)
1600 mm
(63 in.)
18 Backhoe
Max weight
(W/O Bucket)
470 kg
(1036 lbs)
19 Snow Blade Max. width
1524 mm
(60 in.)
20 Snow Blower Max. working width
1524 mm
(60 in.)
When attaching an implement to the tractor, refer to the following specifications recommended as a
maximum capacity of each implement. DO NOT attach any bigger implement than these
specifications. For other implements not mentioned, contact your authorized local dealer.
