3 -22
(14) Throttle pedal (Mechanical)
This pedal is used to control engine speed when
running on the road.
When using the Throttle pedal, the throttle lever
must be placed on the Low speed position.
An electronic control sensor is attached on this
pedal. If there is an error related to this sensor
while the engine is running, the engine speed
will be fixed to 1500 rev/min, so called LIMP
HOME mode. Contact your authorized dealer.
Throttle pedal
▶ DO NOT ride your foot on the clutch pedal while driving.
▶ As a start safety switch is installed for the operator’s safety, depress the clutch
pedal fully for starting engine.
Caution
Clutch pedal
(15) Clutch pedal (Mechanical)
This is used to engage or disengage the main
transmission clutch for starting engine or shifting
transmission gears.
Depress the clutch pedal quickly and fully, and
release it slowly.
Even if depressing the clutch pedal, the PTO
shaft can not be stopped.
Refer to the chapter 3-1-(9), “PTO switch” in this
manual.
