LS tractor R3039H User Manual

②
②②
② Telescopic type
 Pull up the link pin (1) and adjust the stabilizer by
moving the pin in stabilizer holes.
 After the adjustment, insert the pin into the desired
hole and let it tightened firmly by locking spring.
▶ When adjusting the stabilizer’s
length, adjust the implement’s
swinging clearance to be
20~40mm (0.79~1.57 in.) left and
right.
Notice
①
①①
①
(5) Reference of Implement installation part
19
(0.74)
A
B
C
(Max)
G H J L N
CAT.1
19.3
(0.75)
683
(26.8)
12
(0.47)
39
(1.53)
35
(1.53)
22.4
(0.88)
22
(0.86)
44.5
(1.75)
69
(2.71)
76
(2.99)
44
(1.73)
D
(Min)
K
E
(Max)
F
(Min)
4
4 4
4 - 14
Unit : mm
(unit : inch)
