LS tractor R3039H User Manual

(2) Fuse & Main fuse
①
①①
① Fuse check and replacement
 How to replace the fuse
1. Remove the cover of fuse box.
2. Check each fuse and remove the damaged fuse.
3. Replace the new one same as damaged one.
 Capacity and function of each fuse is described in the cover of fuse box.
F10
F11
F1
F2 F3
F4 F5
F6 F7 F8 F9
F1
F2
F3
F4
F5
F6
10A
20A
15A
10A
10A
10A
Mechanical type
Engine stop, Alternator
Instrument panel, horn,
glow relay
Headlight, brake light, sidelight
Work light
PTO
Turn signal light
HST type
Instrument panel, horn,
glow relay
Headlight, brake light, sidelight
Work light
PTO
Turn signal light
Fuse position Fuse capacity
Circuit
Engine stop, Alternator, HST relay
5
5 5
5 - 27
F7
F8
F9
15A
20A
10A
F10 10A
F11 20A
Spare fuse
Instrument panel light
Warning indicators
Spare fuse
Spare fuse
Spare fuse
Instrument panel light
Warning indicators
Spare fuse
Spare fuse
▶ If the same function fuse is damaged repeatedly, contact your authorized dealer
for check instead of using the alternatives such as wire or aluminum foil.
▶ If using the alternatives instead of the rated capacity fuse, it may cause fire which
results in the damage of tractor or injury.
Notice
