A
djusting Engine V
alve
clearance
Ask
y
our authorized
dealer
to check
the valve
clearance.
Clearance
: 0.25mm (0.0098
inch)
If the
gap
is big, the
noise
increase a
nd if the
gap
is small, the
engine
pow
er can be
low.
0.25mm
(0.0098in)
(5) Checking
Nozzle injection
pressure
Contact
your authorized
dealer.
Normal injection
pressure
: 14.7MPa
(2132psi)
5
5
5
5
-
2
4
91
93
