3 -19
Remote control lever
(if fitted)
(3) Hydraulic lift Control (Mechanical Hydraulic Lift, MHL)
z The hydraulic lift system is operated by the position control lever.
Position control lever
Joystick lever(if fitted)
Down speed control lever
Position control lever
Stopper A
① Position control
z This mode sets the position of implements freely
by position control lever operation. Generally,
this mode is used for tiller, fertilizer distributor,
mower, rake etc. In this case, operate the lever
as follows.
1.Push the position control lever forward and let
the implement down by its own weight.
2.Move up the lever to the desired position, the
rear implement shall be located on the position
corresponding to the lever position.
3.If necessary, fix the lowest position of the lever
with the stopper A at the desired position.
