Manitowoc Published 03-29-17, Control # 064-23 v2 4-105
14000 OPERATOR MANUAL SETUP AND INSTALLATION
4
Rope
Clips
Rigging
Line
A1189
A09310
Wire
Rope
Pad
Eye
P1519
FIGURE 4-54
B
D
F
A
E
G
C
No. 1.5
Pad Eye
Item in mm
A 0.63 16,00
B 0.25 6,35
C 1.00 25,40
D 0.44 11,18
E 1.13 28,70
F 0.16 4,06
G 1.31 33,27
Wire Rope
from Drum
Pad
Eye
Load Block Sheaves
EXAMPLE
Boom Point
Sheaves
Pull Rigging Line
with Winch or
Fork-Lift Truck
