Trim/Tabs
The following data is displayed on the Trim/Tabs data screen:
• Trim graph
• Tab graph
• Numeric trim values
• Active Trim status
• Fuel flow rate
a - Trim graph
b - Numeric trim value
c - Active Trim status
d - Fuel flow rate
e - Tab graphs
System
The System screen can be customized with up to five vessel and engine data items. The engine RPM will always be present on
the screen.
NOTE: Depending on the vessel power package, not all of the vessel and engine data options will be available.
The following is a list of vessel and engine data available for selection.
• Coolant pressure
• Coolant temperature
• Boost pressure
• Oil pressure
• Engine hours
• Fuel flow rate
• Intake temperature
• Throttle percent
• Load percent
• Transmission oil temperature
• Transmission oil pressure
• Total fuel used—lifetime
To select data items to be displayed in the System screen, navigate to the Menu.
Section 3 - Main Menu Selections
90-8M0124182 eng DECEMBER 2017 Page 31
