Installation
*INSTALLATION*
186
Installing and removing the
steam oven
For safety reasons, the steam oven
may only be used when it has been
fully installed.
Do not open the door when the
steam oven is on the floor. This could
damage the door.
Do not open the door until the steam
oven has been installed inside the
housing unit.
Maintain the required minimum in-
stallation height of 36" (914mm).
It is vital to observe the connection
data in “Electrical connection” under
“Installation”.
Securing the steam oven in the hous-
ing unit
Risk of damage from incorrect trans-
portation.
Lifting the steam oven by the door
handle could cause damage to the
door.
Use the recessed grips on each side
of the housing to carry the appliance.
The steam generator may malfunc-
tion if the steam oven is not on a
level surface.
The maximum deviation from the
horizontal that can be tolerated is 2°.
 Push the steam oven into the housing
unit and align it in the center of the
housing unit.
When doing so, make sure that the
power cord does not get trapped or
damaged.
 Open the door.
1.
2.
 Insert the mounting aid into the hole
in the front frame.

Miele DGC 7860 Specifications

General

Oven size	Medium
Oven type	Electric
Top heating	Yes
Number of ovens	1
Total oven power	- W
Microwave cooking	No
Oven thermostat range	30 - 225 °C
Number of shelf positions	4
Total oven(s) interior capacity	68 L
Clock type	Electronic
Timer type	Digital
Connected load	3500 W
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Energy efficiency class	-
Energy consumption (conventional)	- kWh
Door hinge	down
Cord length	2 m
Control type	Touch
Door material	Glass
Product color	Gray
Control position	Front
Housing material	Stainless steel
Appliance placement	Built-in

Weight and Dimensions

Depth	567 mm
Height	596 mm
Weight	46000 g
Installation compartment depth	555 mm
Installation compartment width	568 mm
Installation compartment height	595 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	590 mm
