Labscale Pump Module
The Labscale Pump Module consists of a panel mounted electronic
diaphragm pump and a panel mounted speed controller that can
be installed in the Labscale Stir Base. The Labscale Pump Module
is mounted inside the base if a complete system was purchased. If
the pump unit was purchased separately, it is packed as shown in
figure 5.
Note: This Labscale Pump Module can only be used with the
Millipore Labscale Stir Base.
4 clamps 4 ttings
1 Installation
Instructions
3 feet of Silicone
(translucent) tubing
1/8" (3mm) ID
1 x 1 ft (0.3m) of
Sta-Pure® peristaltic
pump tubing
1/8 in. (3 mm) ID.
Figure 5: Labscale Pump Module Catalog No. XX42PMP01
4 clamps 4 ttings
1 Installation
Instructions
3 feet of Silicone
(translucent) tubing
1/8" (3mm) ID
1 x 1 ft (0.3m) of
Sta-Pure® peristaltic
pump tubing
1/8 in. (3 mm) ID.
4 clamps 4 ttings
1 Installation
Instructions
3 feet of Silicone
(translucent) tubing
1/8" (3mm) ID
1 x 1 ft (0.3m) of
Sta-Pure® peristaltic
pump tubing
1/8 in. (3 mm) ID.
Figure 6: Labscale Pump Module Accessories
