Labscale TFF System Setup
See “Labscale 500mL Reservoir Setup” section for detailed setup
instructions.
COVER
MILLEX VENT
FILTER
VENT PORT
FEED PRESSURE GAUGE
RETENTATE
PRESSURE
GAUGE
RESERVOIR
SHUT-OFF VALVE
TANK OUT PORT
FEED IN PORT
RET OUT PORT
PERM 2 OUT
PERM 1 OUT
RET IN PORT
RETENTATE TUBING
PERMEATE TUBIN
G
RETENTATE
BACK PRESSURE
VALVE
DIA RECIRC
Figure 7: Labscale 500 mL Reservoir set up.
