MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
4.2.19 P.1
1
2
3
4
5
6
7
8
R.1.1
Maintenance Manual > Adjustment Items > Adjustment Function > REPLACE PARTS
Model CJV30/TPC Issued 2008.08.04 Revised 2009.06.30 F/W ver. 1.00 Remark
1.1
Rev.
4.2.19 REPLACE PARTS
 Function
Displays the replacement history of the following parts/unit or registers replacement date thereof.
 Parts subject to the replacement
 Registration procedure
1. Select [REPLACE PARTS] from the operation menu.
2. Select [REGISTRATION].
[]/[]: Changes items
[ENTER]: Finalizes (To the next screen.)
3. Select the parts replaced and register the date and the part
number referring to the list shown above.
[]/[]: Switches the names of parts.
[ENTER]: Finalizes (To the next screen.)
 Example of displaying the part-replacement history
To see the part-replacement history, select [HISTORY] in Step
2 and make the appropriate part displayed.
[]/[]: Switches the display of the parts.
In this machine, the timing for replacement of parts is determined based on this item.
When a part in question is replaced, never forget to register the replacement date.
Type Part number
PUMP Enter the date only. (Do not input the number.)
CAP Enter the date only. (Do not input the number.)
DUMPER Registration of A to H (nozzle number)
Print Head *As for a head, since the replacement date is automatically recorded at start-up after replacement, the
registration is not required. (Confirmation of history is possible.)
<LOCAL.1> [#01]
FUNCTION
#ADJUST <ent>
#ADJUST
REPLACE PARTS <ent>
[FUNCTION]
#REPLACE PARTS
REGISTRATION <ent>
HISTORY <ent>
#REPLACE PARTS
PARTS :PUMP
:CAP
:DUMPER
PUMP
00.00.?? : No.1
HEAD
[ 0] 06.10.10 : No.2
The position of the damper and the print head
(Top view of head)
A
Designate with nozzle row (A to H)
B C D E F G H
