© 2009 MIMAKI ENGINEERING CO.,LTD.
6.1.1 P.1
1
2
3
4
5
6
7
8
R.1.0
Maintenance Manual > Disassembly and Reassembly > Covers > Cover Layout
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
Rev.
6.1.1 Cover Layout
Printer Front
CY Cover F
Maintenance Cover L
Right Cover
KB Cover
C Station Cover 2
Station Cover D
Station Cover U
Main Body
Frame Cover L
Left Station
Cover
Heater Connector
Cover
Head Cover
C Head Cover
