Maintenance Manual > Operating Principle > Maintenance Function > DISCHARGE&WASH
Model CJV30/TPC Issued 2008.08.04 Revised F/W ver. 1.00 Remark
1.0
1.2.7 DISCHARGE&WASH
Indication on LCD
Processing sequence
Step Processing Description
Indication
on LCD
1 Ink discharging 1. Remove the ink cartridges (from all the slots).
(*Monitored with cartridge sensors)
2. Open the cartridge valve and drive the ink suction pump motor to discharge ink.
3. When a waste ink tank warning occurs, the warning message is displayed.
• For details, see "1.2.9 Waste Ink Tank Warning".
2 Cleaning 1. Insert washing liquid cartridges (into all the slots).
(*Monitored with cartridge sensors)
2. Cleaning the inside of the tubes
• Opening the cartridge valve and starting the ink suction pump motor
When a waste ink tank warning occurs, the warning message is displayed.
(For details, see "1.2.9 Waste Ink Tank Warning".)
3. Performing head vibration operation (starting the Y-axis motor)
3 Discharging of washing
liquid
1. Remove the washing liquid cartridges (from all the slots).
(*Monitored with cartridge sensors)
2. Open the cartridge valve and drive the ink suction pump motor to discharge
washing liquid.
3. When a waste ink tank warning occurs, the warning message is displayed.
• For details, see "1.2.9 Waste Ink Tank Warning".
4 Repeating 1. Executing 2 to 3 again.
5 Operation selection 1. Select processing as below.
[] Re-WASH : No. 3 4 are executed again
[] END : to next step.
6 Whether to discharge
maintenance washing
liquid
1. Select processing as below.
[] DISCHARGE : to next step.
[] END : to Step 9 (End)
7 Maintenance washing
liquid discharge
1. Discharge maintenance washing liquid.
• For details, see "1.2.8 Maintenance Washing Liquid Filling and Discharge".
8 End 1. (Once the ink discharge operation of this cleaning function is executed, the
heads will be empty of ink.)
The washing liquid cartridge does not incorporate an IC chip.
Therefore, IC chip read error is recognized to be normal.
Display during maintenance
Remove:InkCartridges
MMCCYYKK
Display during maintenance
DISCHARGE
00:00
Display during maintenance
Set:WashingCartridges
12345678
Display during maintenance
ABSORPTION
00:00
Display during maintenance
Remove:Cartridges
12345678
Display during maintenance
SELECT:
END< >Re-WASH
Display during maintenance
Maint.WashLiquid
END < >DISCHARGE
Display during maintenance
Remove:Maint.Wash
To Next Page
