MIMAKI JV5 Series Maintenance Manual

© 2009 MIMAKI ENGINEERING CO.,LTD.
8.3.1 P.1
1
2
3
4
5
6
7
8
R.1.1
Maintenance Manual > Operation Flow > Cut Mode > LOCAL / REMOTE
Model CJV30/TPC Issued 2008.08.04 Revised 2010.11.05 F/W ver. 2.50 Remark
1.1
Rev.
8.3.1 LOCAL / REMOTE
<LOCAL.C> [#01]
CUT1 (30/ 60/ 0.30)
ORIGIN SET UP
0.0 ----
ORIGIN SET UP
 ORIGIN 
[], [], [], []
MEDIA CUT
<ENT>
MEDIA CUTTING
PLEASE WAIT
[END]:To LOCAL
SETUP DRAWING AREA
0.0 ----
 DRAWING AREA 
[END]:To LOCAL
[FUNCTION]
[FEED]
CUTTER SCOOTING
<ENT>
PLEASE WAIT
[HEATER/CUTER]
TEST CUT
<ENT>
 TEST CUT 
[TEST PRINT/TEST CUT]
MEDIA FEED
: 0.1m
 MEDIA FEED 
[CLEANING/FEED]
[PEN]
[CUT2]
DATA CLEAR
<ENT>
 DATA CLEAR 
[DATA CLEAR]
TEMPERATURE CONTROL!
PLEASE WAIT
PRE PRT AFT
35
 C 35  C 35  C
[REMOTE] *
Displayed alternately
 REMOTE.C  [#01]
CUT1 (30/ 60/ 0.30)
Target temperature reached / [ENTER]
 Not displayed when target
temperature has been reached.
SS21INK MMCCYYKK
REMAIN 99999999
HEAD HEIGHT: Thin
MEDIA WIDTH: 1000mm
[ENTER]
CJV30-100 V1.00
MRL-III V1.30
 Not displayed when target
temperature has been reached.
(Same as in PRINT MODE.)
NON-ORIGINAL INK
MMCCYYKK
[FUNCTION]
[] + []: Changes error display
[]: To the next screen
[]: To the previous screen
[END]: To LOCAL
 At occurrence of error
[MODE CHANGE]
Enters PRINT MODE
:0.1 to 51.0m
SPD PRS OFS
[CUT1] 30 60 0.30
[USER TYPE/TOOL]
DIST.COMP. [CUT1]
<ENT>
[FUNCTION]
DIST.COMP. [CUT1]
X = 500 Y = 200
DIST.COMP. [CUT1]
DRAW SHIFT = 0mm
DIST.COMP. [CUT1]
XR = 0.0 XL = 0.0
DIST.COMP. [CUT1]
Y = 0.0
[END] :To LOCAL [END] :To LOCAL
Pattern drawing
[] / []
HEATER Power-off
<ent>
