Mindray DPM 4 Service Manual

4-2
8 8002-30-36209 CF Card assembly 1
9 M04-000305--- Self-tapping screw PT3X12 2
10 8002-30-36342 Back housing assembly 1
11 8002-30-36378 Back housing assembly (supporting wireless
network adapter)
1
12 8002-30-36204 Parameter connector assembly(with CO2) 1
13 M04-004015--- Gasketed cross-head screw M3*8 4
14 8002-21-36169 Parameter connector panel(with CO2) 1
15 8002-20-36222 Parameter connector label(with CO2) 1
16 9211-30-87429 Water trap assembly 1
17 M04-051003--- Cross-pad self-tapping screw PT2X6 6
4.1.2 DPM4 Front Bezel Assembly
Figure 4-2 DPM4 display front bezel assembly
