Mindray DPM 4 Service Manual

4-4
4.1.3 DPM4 Back Housing Assembly (Lithium Battery)
Figure 4-3 DPM4 back housing assembly
NO Material code Part & Specification Quantity
1 8002-20-36167 Back housing 1
2 8000-20-10339 Sealed cushion for back housing 1
3 8000-20-10220 Feet 2
4 8002-20-36219 Battery Door bond 1
5 M04-000802--- Pad GB97.1 3 1
6 M04-003105--- Self-tapping screw PT3X8 3
7 8002-20-36217 Speaker press plate 1
8 8002-20-36218 Cushion for Speaker press plate 1
9 8002-21-36202 Speaker 1
10 M04-051085--- Self-tapping screw PT4X14 2
11 M04-004702--- Gasket GB97.1 4 2
