Mindray DPM 4 Service Manual

4-5
12 8002-20-36224 Fan cushion 1
13 8002-20-36237 Handle 1
14 8002-20-36174 Battery door 1
4.1.4 Screen Assembly
Figure 4-4 Screen assembly
NO Material code Part & Specification Quantity
1 M04-002405--- Cross-head screw M2X6 2
2 900E-10-04913 INVERTOR 'TDK'' 1
3 0010-10-12358 TFT screen 8.4"(800X600) 1
4 8000-20-10217 Stud screw for screen 4
5 8000-20-10231 Sponge cushion1 2
6 8002-20-36175 Screen supporter 1
7 8000-20-10232 Sponge cushion2 2
8 M04-051045--- Cross-head screw M2.5X6 4
