Mindray DPM 4 Service Manual

4-7
4.1.6 Parameter Connector Assembly
Figure 4-6 Parameter connector assembly
NO Material code Part & Specification Quantity
1 M04-051003--- Self-tapping screw PT2X6 12
2 0010-10-12279 ECG connector 1
3 0010-21-12306 6PIN SPO2 Cable 1
4 8002-21-36171 Panel for parameter connector(with CO2) 1
5 0010-20-12194 NIBP Connector 1
6 6200-20-11614 Exhaust 1
7 9000-20-07459 Nut for Temp connector 2
8 M04-000501--- Nut GB6170 M5 1
9 6000-10-02010 IBP PROBE SOCKET 2
10 M33-109002--- Temp connector 2
