4-10
4. Wait till the Temp value displayed on the monitor stabilizes. Verify that the displayed
value is 37±0.1℃.
Please contact our service personnel if the Temp test fails.
4.4.6 Nurse Call Reply Performance Test
Tool required:
Oscilloscope
1. Connect the nurse call cable to the Multifunctional Connector of the equipment.
2. Select [Main
→
][Maintenance >>
→
][User Settings >>
→
] enter the required
password]
→
Ok
→
][Nurse Call >>].
3. In the [Nurse Call Setup] menu, select the [Alarm Level] and [Alarm Category], and set
[Contact Type] to [Normally Open, and [Signal Type] to [Continuous].
4. Click
to save the changes and quit the menu.
5. Select [Main
→
][Maintenance >>
→
][Demo >>
→→
] enter the required password [Ok]
to enter demo mode.
6. Make the monitor to generate an alarm and check that the oscillograph outputs
continuous high level when there is an alarm.
7. Quit the demo mode, and repeat step 2.
8. In the [Nurse Call Setup] menu, select the [Alarm Level] and [Alarm Category], and
set [Contact Type] to [Normally Open, and [Signal Type] to [Pulse].
9. Repeat steps 4 and 5.
10. Make the monitor to generate an alarm and check that the oscillograph displays
positive pulses of 1s width when there is an alarm.
4.4.7 Bar Code Scanner Test
Tool required:
None
1. Aim the bar code scanner at the target bar code. Adjust the field of view to capture the
bar code.
2. Hold the trigger until the bar code scanner gives a beep, indicating the bar code is
successfully decoded. Meanwhile, the scanned characters are displayed on the monitor.
Please contact our service personnel if the bar code scanner fails to work normally.
