Mindray VS-900 Service Manual

7-12
SN PN Description FRU part number Remarks
5
043-008862-00 VS900 TEMP BO X 043-008862-00
/
6 051-001419-00
Temp on-position detection board
PCBA
051-001419-00
/
7 / Chassis / /
8
043-008842-00
External compartment for Temp
module (VS)
043-008842-00
/
9 049-000547-01 Temp cover for VS-600 049-000547-01 /
10 M09A-20-62064 Silicon buttons M09A-20-62064 /
11 051-001435-00 Predictive Temp module PCBA 051-001435-00 /
12 /
Screw, pan head cross recessed
M2X6
/ /
13 / Temp module support for VS-600 / /
14 / Screw, Flat Head Phillips, M3X8 / /
15 /
Screw, pan head cross recessed
M3X6
/ /
/ / Silicone tube / /
/ 009-003368-00
VS-900 predictive Temp board
cable
009-003368-00
/
/ 009-003239-00
VS-900 Cable between the Temp
module and power management
board
009-003239-00 /
/ 009-003240-00
VS-900 Cable between the
isolation power board and Temp
board
009-003240-00 /

Mindray VS-900 Specifications

General

RESP	Impedance Respiration
Display Size	12.1 inch
Parameters	ECG, SpO2, NIBP, RESP, TEMP
ECG	3-lead or 5-lead ECG monitoring
IBP	Optional, up to 2 channels
CO2	Optional, Sidestream or Mainstream CO2 monitoring
AG	O2, N2O, CO2
ANES	Multiple anesthetic agents
Connectivity	Ethernet, USB
Power Supply	AC power and battery
