Field Wiring
12
Field Wiring
General Field Wiring Considerations
Because most of the Field Wiring on the FA-200’s is to the Main Boards on the swinging dead front, it is very
important to properly dress the wires so as not to place stress on either their connection to the boards, or running to
conduit. The Figure below shows the required wiring techniques.
Figure 10: General Field Wiring Considerations
USE AT LEAST
3 WIRE TIES
AS SUPPLIED
THROUGH HOLES
ON DEADFRONT
WIRE TIE
IN 2 PLACES
TO BACK OF
ENCLOSURE
DRESS WIRES NEAR
TOP OF ENCLOSURE
CLEAR OF ADDER
MODULES
