MDS-E/EH Series Instruction Manual
15 Appx. 6: Higher Harmonic Suppression Measure Guidelines
511
IB-1501229-F
15.1.1 Calculating the Equivalent Capacity of the Higher Harmonic Generator
As a principle, the higher harmonic suppression measure guidelines must be followed by the customer.
(1) Calculating the total equivalent capacity (Step 1)
Calculate the total equivalent capacity with the following expression.
Total equivalent circuit: Po = Σ • Ki • Pi
Ki :Conversion coefficient (Refer to following table)
Pi :Rated input capacity of each device
(Table 1) Rated capacity of each unit
(Note) The rated capacity Pi above, is the value used to calculate whether the product corresponds to the higher
harmonic guidelines. Thus, the value will differ from the actual power facility's capacity.
(The power supply unit is not included.)
(Table 2) Circuit class and conversion coefficient for each unit
(Note) This applies when an AC reactor is installed on the power supply unit.
(Table 3) Limit values for total equivalent capacity
If the total equivalent capacity Po exceeds the limit value given in (Table 3), proceed to "(2) Calculating the higher
harmonic current flow".
Measures are not required if the value is not exceeded.
Unit type
MDS-
Rated
input
capacity
pi [kVA]
Unit type
MDS-
Rated
input
capacity
pi [kVA]
Unit type
MDS-
Rated
input
capacity
pi [kVA]
Unit type
MDS-
Rated
input
capacity
pi [kVA]
E- EH- E- EH- E- EH- E- EH-
SP-20 - 0.97 SP2-20 - 1.94 V1-20 V1-10 1.0 V2-20 V2-10 2.0
SP-40 SP-20 2.81 SP2-40 - 5.62 V1-40 V1-20 1.6 V2-40 V2-20 3.2
SP-80 SP-40 6.77 SP2-80 - 13.54 V1-80 V1-40 2.7 V2-80 V2-40 5.4
SP-160 SP-80 13.1
SP2-
16080
- 15.84
V1-160 V1-80 5.9 V2-160 V2-80 11.8
SP-200 SP-100 21.8 V1-160W V1-80W 9 V2-160W V2-80W 18.0
SP-240 - 25.9 V1-320 V1-160 11.5 - V2-160 23.0
SP-320 SP-160 34.7 V1-320W V1-160W 13.1 V3-20 - 3.0
SP-400 SP-200 42.8 V1-200 21.7 V3-40 - 4.8
SP-640 SP-320 63.7
SP-480 86.8
SP-600 120.2
Name Model
Circuit
class
Circuit type
Conversion
coefficient
Ki
Servo drive unit MDS-E/EH-V1/V2/V3 Series 3
3-phase bridge (with smoothing capacitor)
With AC reactor (Note 1)
K32=1.8
Spindle drive unit MDS-E/EH-SP/SP2 Series 3
3-phase bridge (with smoothing capacitor)
With AC reactor (Note 1)
K32=1.8
Incoming voltage Total of 6-pulse equivalent capacity
6.6kV 50kVA
22/33kV 300kVA
66kV or more 2,000kVA
