Motorola 700 Series User Manual

Memory Maps
1-33
1
VMEbus Memory Map
This section describes the mapping of local resources as viewed by
VMEbus masters. Default addresses for the slave, master, and
GCSR address decoders are provided by the ENV command. Refer
to Appendix A.
VMEbus Accesses to the Local Bus
The VMEchip2 includes a user-programmable map decoder for the
VMEbus-to-local-bus interface. The map decoder allows you to
program the starting and ending address and the modifiers that the
MVME162LX responds to.
VMEbus Short I/O Memory Map
The VMEchip2 includes a user-programmable map decoder for the
GCSR. The GCSR map decoder allows you to program the starting
address of the GCSR in the VMEbus short I/O space.
