Motorola ASTRO SPECTRA User Manual

80 6881086C22-B
PLN1360C Tone Remote Control Board
Electrical Parts List
Ref. Des. Part Number Description
- 2605255S01 HT SINK
- 2605455Z04 SHLD 3 X 3.5 COVER
C100 2113740F51 CAP CHIP REEL CL1 +/-30 100
C101 2113741A21 CAP CHIP CL2 X7R REEL 1000
C102 2311049A19 CAP TANT CHIP 10 10 25 A/P
C104 2311049A14 CAP TANT CHIP 4.7 1020 A/P
C105 2113741A45 CAP CHIP CL2 X7R REEL
10000
C106 2113740F51 CAP CHIP REEL CL1 +/-30 100
C107 2113741A45 CAP CHIP CL2 X7R REEL
10000
C108 2113741A21 CAP CHIP CL2 X7R REEL 1000
C109 2113741A45 CAP CHIP CL2 X7R REEL
10000
C110 2113741F49 CAP CHIP CL2 X7R REEL
10000
C111 2113743K05 CER CHIP CAP .039UF
C112 2113741A45 CAP CHIP CL2 X7R REEL
10000
C113 2113741A13 CAP CHIP CL2 X7R REEL 470
C114 2113741A45 CAP CHIP CL2 X7R REEL
10000
C117 2113741B69 CAP CHIP CL2 X7R REEL
100000
C118 2113741B69 CAP CHIP CL2 X7R REEL
100000
C119 2311049A08 CAP TANT CHIP 1 10 35 A/P
C120 2113741A13 CAP CHIP CL2 X7R REEL 470
C121 2113741A37 CAP CHIP CL2 X7R REEL 4700
C122 2311049A23 CAP TANT CHIP 47 10 10
C123 2311049A23 CAP TANT CHIP 47 10 10
C124 2311049A19 CAP TANT CHIP 10 10 25 A/P
C125 2311049A19 CAP TANT CHIP 10 10 25 A/P
C126 2311049A19 CAP TANT CHIP 10 10 25 A/P
C127 2311049A19 CAP TANT CHIP 10 10 25 A/P
C128 2311049A19 CAP TANT CHIP 10 10 25 A/P
C129 2113740A33 CAP CHIP REEL CL1 +/-30 15
C130 2113740A33 CAP CHIP REEL CL1 +/-30 15
C131 2311049A08 CAP TANT CHIP 1 10 35 A/P
C132 2113741B69 CAP CHIP CL2 X7R REEL
100000
C133 2311049A08 CAP TANT CHIP 1 10 35 A/P
C134 2113741B69 CAP CHIP CL2 X7R REEL
100000
C135 2113741A13 CAP CHIP CL2 X7R REEL 470
C136 2311049A08 CAP TANT CHIP 1 10 35 A/P
C137 2113741A13 CAP CHIP CL2 X7R REEL 470
C138 2113741A13 CAP CHIP CL2 X7R REEL 470
C139 2113741A13 CAP CHIP CL2 X7R REEL 470
C140 2113741A13 CAP CHIP CL2 X7R REEL 470
C141 2113741A13 CAP CHIP CL2 X7R REEL 470
C142 2113741A13 CAP CHIP CL2 X7R REEL 470
C143 2113741A13 CAP CHIP CL2 X7R REEL 470
C145 2113741A13 CAP CHIP CL2 X7R REEL 470
C146 2113741A13 CAP CHIP CL2 X7R REEL 470
C147 2113741A13 CAP CHIP CL2 X7R REEL 470
C148 2113741B69 CAP CHIP CL2 X7R REEL
100000
C149 2113741A13 CAP CHIP CL2 X7R REEL 470
C150 2113741A13 CAP CHIP CL2 X7R REEL 470
C151 2113741A13 CAP CHIP CL2 X7R REEL 470
C152 2113741A13 CAP CHIP CL2 X7R REEL 470
C153 2113741A13 CAP CHIP CL2 X7R REEL 470
C154 2113741A13 CAP CHIP CL2 X7R REEL 470
C155 2113741A13 CAP CHIP CL2 X7R REEL 470
C156 2113741A13 CAP CHIP CL2 X7R REEL 470
C157 2113741A13 CAP CHIP CL2 X7R REEL 470
C158 2113741A13 CAP CHIP CL2 X7R REEL 470
C159 2311049A14 CAP TANT CHIP 4.7 1020 A/P
C160 2311049A14 CAP TANT CHIP 4.7 1020 A/P
C161 2311049A14 CAP TANT CHIP 4.7 1020 A/P
C162 2380090M25 CAP ALU 100UF 25V
C163 2380090M25 CAP ALU 100UF 25V
C164 2311049A07 CAP TANT CHIP 1 10 16 A/P
C165 2113741A13 CAP CHIP CL2 X7R REEL 470
C166 2113741A13 CAP CHIP CL2 X7R REEL 470
C167 2113741A13 CAP CHIP CL2 X7R REEL 470
C168 2113741A13 CAP CHIP CL2 X7R REEL 470
C169 2113741A13 CAP CHIP CL2 X7R REEL 470
Ref. Des. Part Number Description
C170 2113741A13 CAP CHIP CL2 X7R REEL 470
C171 2113741A13 CAP CHIP CL2 X7R REEL 470
C301 2113740A20 CAP CHIP REEL CL1 +/-30 5.1
C302 2113741B69 CAP CHIP CL2 X7R REEL
100000
C303 2113741B69 CAP CHIP CL2 X7R REEL
100000
C304 2113741A45 CAP CHIP CL2 X7R REEL
10000
C305 2113741B69 CAP CHIP CL2 X7R REEL
100000
C307 2113741A13 CAP CHIP CL2 X7R REEL 470
C308 2113741B69 CAP CHIP CL2 X7R REEL
100000
C309 2113741B69 CAP CHIP CL2 X7R REEL
100000
C310 2113741A13 CAP CHIP CL2 X7R REEL 470
C311 2113741B69 CAP CHIP CL2 X7R REEL
100000
C312 2113740A20 CAP CHIP REEL CL1 +/-30 5.1
C313 2113740A79 CAP CHIP REEL CL1 +/-30
1000
C314 2113741B69 CAP CHIP CL2 X7R REEL
100000
C315 2113740A46 CAP CHIP REEL CL1 +/-30 47
C316 2113741B69 CAP CHIP CL2 X7R REEL
100000
C319 2113740A63 CAP CHIP REEL CL1 +/-30 220
C320 2113741A13 CAP CHIP CL2 X7R REEL 470
C322 2113741A13 CAP CHIP CL2 X7R REEL 470
C323 2113741A13 CAP CHIP CL2 X7R REEL 470
C324 2113741A13 CAP CHIP CL2 X7R REEL 470
C325 2113741A13 CAP CHIP CL2 X7R REEL 470
C326 2113741A13 CAP CHIP CL2 X7R REEL 470
C327 2113741A13 CAP CHIP CL2 X7R REEL 470
C328 2113741A13 CAP CHIP CL2 X7R REEL 470
C501 2382174V01 CAP LYTIC 4.7UF 200V 20% N/
PLR
C502 2382174V01 CAP LYTIC 4.7UF 200V 20% N/
PLR
C503 2380090M07 CAP ALU 47 20 16.0V SURF
MT
Ref. Des. Part Number Description
C504 2113741A53 CAP CHIP CL2 X7R REEL
22000
C505 2113741B69 CAP CHIP CL2 X7R REEL
100000
C506 2380090M22 CAP ALU 4.7 20 50V SURF MT
C507 2380090M25 CAP ALU 100UF 25V
C508 2113741A53 CAP CHIP CL2 X7R REEL
22000
C509 2113740A24 CAP CHIP REEL CL1 +/-30 6.8
C510 2113741B69 CAP CHIP CL2 X7R REEL
100000
C511 2113741B69 CAP CHIP CL2 X7R REEL
100000
C512 2113741B63 CAP CHIP CL2 X7R REEL
56000
C513 2113741B69 CAP CHIP CL2 X7R REEL
100000
C514 2113740A43 CAP CHIP REEL CL1 +/-30 39
C515 2311049A03 CAP TANT CHIP A/P .22 10 35
C516 2113740A43 CAP CHIP REEL CL1 +/-30 39
C517 2113740A43 CAP CHIP REEL CL1 +/-30 39
C518 2113741B69 CAP CHIP CL2 X7R REEL
100000
C519 2113741B69 CAP CHIP CL2 X7R REEL
100000
C520 2311049A03 CAP TANT CHIP A/P .22 10 35
C521 2113740A67 CAP CHIP REEL CL1 +/-30 330
C522 2113743G21 CER CHIP CAP 1.0 UF
C523 2113740A55 CAP CHIP REEL CL1 +/-30 100
C524 2113740A79 CAP CHIP REEL CL1 +/-30
1000
C525 2113741B69 CAP CHIP CL2 X7R REEL
100000
C526 2113741B69 CAP CHIP CL2 X7R REEL
100000
C527 2113740A43 CAP CHIP REEL CL1 +/-30 39
C528 2113740A79 CAP CHIP REEL CL1 +/-30
1000
C529 2113741B69 CAP CHIP CL2 X7R REEL
100000
C530 2311049A04 CAP TANT CHIP A/P .33 10 35
C531 2113741B69 CAP CHIP CL2 X7R REEL
100000
Ref. Des. Part Number Description
